| Camera |
| Image Sensor |
1/3″ Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Lens |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm, horizontal FOV 95.7°, vertical FOV 51.7°, diagonal FOV 113.7°
4 mm, horizontal FOV 79.6°, vertical FOV 43.2°, diagonal FOV 93.2° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F1.28 |
| PTZ |
| Movement Range (Pan) |
0° to 340° |
| Movement Range (Tilt) |
0° to 80° |
| Pan Speed |
Up to 20°/s |
| Tilt Speed |
Up to 25°/s |
| DORI |
| DORI Range |
2.8 mm D: 63.9 m, O: 25.4 m, R: 12.8 m, I: 6.4 m
4 mm D: 77.6 m, O: 30.8 m, R: 15.5 m, I: 7.8 m |
| Illuminator |
| Supplement Light Type |
IR, White Light |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Video |
| Main Stream |
50 Hz: 12.5 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Audio |
| Audio Compression |
G.711ulaw |
| Audio Bit Rate |
64 Kbps (G.711ulaw) |
| Audio Sampling Rate |
8 kHz / 16 kHz |
| Environment Noise Filtering |
Yes |
| Network & Mobile |
| Simultaneous Live View |
Up to 6 channels |
| API |
ISAPI |
| User/Host |
Up to 32 users (3 user levels: administrator, operator, user) |
| Client |
Hik-Connect |
| Cellular Standard |
LTE-FDD, LTE-TDD, UMTS |
| Frequency Bands |
EU: LTE-FDD B1/3/5/7/8/20/28
LA: LTE-FDD B2/3/4/5/7/8/28/66 |
| Data Rate & SIM |
EU/IN/LA: Cat 1 (Uplink 5.1 Mbps, Downlink 10.3 Mbps)
NA/JP: Cat 4 (Uplink 50 Mbps, Downlink 150 Mbps)
SIM Card: Nano SIM |
| Image |
| Image Settings |
Saturation, brightness, contrast, sharpness, white balance |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR, Digital WDR |
| Interface & Events |
| On-Board Storage |
MicroSD/microSDHC/microSDXC slot, up to 512 GB |
| Audio I/O |
1 built-in microphone, 1 built-in speaker |
| Reset Key |
Yes |
| Basic Event & Linkage |
Motion detection (human and vehicle target filtering)
Linkage: Notify center, trigger recording/capture, audible warning, upload to memory card |
| Battery Power |
| Battery Specs |
Type: Lithium | Voltage: DC 6V to 8.4V
Capacity: 9000 mAh (3.7 V) | Max Output/Charging: 8.4V
Life: More than 800 cycles |
| Battery Temp Range |
Charging: 0 °C to 45 °C (32 °F to 113 °F)
Discharging: -20 °C to 55 °C (-4 °F to 131 °F) |
| General & Certifications |
| Power Supply |
12 V, 0.75 A |
| Material & Dimensions |
Plastic | 208 mm × 131 mm × 282.7 mm (8.2″ × 7.0″ × 11.1″)
Weight: Approx. 850 g (1.9 lb.) |
| Package Details |
Dimension: 386 mm × 201 mm × 225 mm (15.2″ × 7.9″ × 8.9″)
Weight with Package: Approx. 5400 g (11.9 lb.) |
| Operating Conditions |
Storage: -30 °C to 60 °C (-22 °F to 140 °F)
Startup/Operating: 0 °C to 50 °C (32 °F to 122 °F), Humidity 95% or less |
| Protection Level |
IP66: IEC 60529-2013 |
| Approvals & Standards |
RF: CE-RED (EU regions)
EMC: CE-EMC, IC, KC
Safety: CB, CE-LVD, BIS
Environment: CE-RoHS, WEEE, Reach |
